Standard configuration:

Software control:

• Positioning control Classic Bend 10,1″ screen on swiveling arm
• Radius function

Clamping beam:

• Clamping beam stroke 350 mm (325 mm with manual clamping device)
• Clamping beam geometry 48°
• Middle motor clamping beam drive: 3.0 kW (controlled through contactors, 20 mm/sec, trapezoidal spindle)
• Manual tool clamping device for clamping beam

Folding beam:

• Drive: 2 × 2.2 kW (converter-controlled, 85°/sec)
• Manual folding beam adjustment of 80 mm
• Manual tool clamping device for folding beam

Bottom beam

• Bottom beam blade ca. 1 100 N/mm2 one-piece
  (Minimum gauge variies according to equipment)

Back gauge:

• Motorized back gauge up to 1000 mm, pneumatic pop-up gauge fingers, sheet support table with balls, recirculated ball screws

Others:

• Footswitch
• Anchor plates, incl. dowels
• Standard machine without folding- and clamping beam tools

Clamping beam

• Clamping beam geometry 180°
• Hydraulic tool clamping

Folding beam

• Power-Package folding beam increases the bending capacity by 1 mm: reinforced drive incl. folding blade 35 mm (1100 N/mm²) requires converter package (65°/sec)
• Central crowning device, manual
• Motorized folding beam adjustment 80 mm
• Central crowning device motorized, requirement: POS 2000 Professional and motorized folding beam adjustment
• Clamping device, pneumatic
• Technology package POS 2000 Professional
• Technology package nanoTouch

Table and back gauge

• Motorized back gauge up to 1600 mm, closed, two sectors with the pneumatic lowering device, sheet support table with balls, recirculated ball screws (+/- 0,1)
• Back gauge extension to J- or U-gauge possible: Basis: motorized gauge up to 1600 mm, closed
• two fixed square arms (left and right)
• two pneumatic pop-up square arms (only in connection with POS 2000 Professional)

Software control

• POS 2000 Professional PC Version (external programming), 1st licence
• POS 2000 Professional PC Version

Safety and others

• Additional equipment for 2-man operation control by accident prevention rules required
• Operation from the rear, in addition to 2nd footswitch and protection via light barrier
• Foot switch on the rail for lateral movement
• Voltage transformer 12 kVA
• Air conditioner
• Various bottom beam, folding beam, and clamping beam tools

POS 2000 Professional:

The standard for industrial folding machines

The proven POS 2000 Professional makes programming a folding machine fast and comfortable. The desired program components can be selected from a comprehensive and expandable catalogue, and the angle and side dimensions can be easily changed by pressing the monitor.

The control software displays exactly what the machine is doing: The folding machine, workpiece, and tool are displayed schematically and updated for every bending step. Anyone who programs work preparation away from the machine can test the quality of their program using the bending simulation, which effectively avoids waste and delays during production.

The software not only controls the machine but also offers assistance to the user: all of the necessary operator activities, like turning, rotating, etc., are displayed for each bending step.

NanoTouch:

The most clearly laid-out alphanumeric control

The latest software invention from Schröder Group is perfect for workshop and factory applications: nano Touch is a modern alphanumeric control that serves as the standard software for the folding machines MAK V and MAKV S.

Nano:

Touch controls the clamping and folding beams using a path measurement system, and the motorized backstop is controlled via the digitally controlled frequency inverter. The user interface is clearly laid out and combines easy-to-understand icons with text and numerical displays.

The versatile solution for lean sheet metal forming in a locksmith, maintenance, and plumber workshops.
